Street Solutions UK · SKU:
086219
Vertical Pipe Protectors - Wall & Ground Mounted
Hot-dip galvanised pipe protector with yellow powder coat, protects pipework up to 249mm diameter. Wall and ground fixing.
£258.33
each, ex VAT
£309.99
inc VAT
Ships in 1 to 2 working days
Vertical Pipe Protectors - Wall & Ground Mounted - 1000mm is backordered and will ship as soon as it is back in stock.
Buy more, pay less
Per unit, ex VAT. Applied automatically.
Ships in
1 to 2 working days
Formal quote back in 3 hours. No account needed.
Quote in 3 hours
No account needed
- Made in the UK
- Pay in 30 days with Klarna. No fee. Learn more
- Next Day Delivery Available
- Pay in 30 days with a Trade Account. No fees.
- UK stock. Stock and lead time are shown above.
- Seen it cheaper? We beat any genuine quote. 0161 706 0479
Frequently purchased with
Tick to add
Complete the kit
0 add-ons selected · £0.00 ex VAT
You may also like
See all hand tools ›Other hand tools in the range
Vertical Pipe Protectors - Wall MountedPipe and Conduit Protection - Wall Mounted
£258.33 ex VAT
£309.99 inc VAT
PVC Drain & Soil Pipe Chamfer ToolHand Tools & Bags
£59.82 ex VAT
£71.78 inc VAT
BLACK BULL FLEX Low Level Impact Protection System HYBRID - Lateral Rail for End & Middle PostsImpact Protection Railings
£60.91 ex VAT
£73.09 inc VAT
Vertical Pipe Protectors - Wall & Ground Mounted
Regular priceFrom
£309.99
Unit price
Unavailable
Vertical Pipe Protectors - Wall & Ground Mounted - 1000mm is backordered and will ship as soon as it is back in stock.
Why it works
Why choose this pipe protector
Protects pipework from impact
A three-bar steel cage shields exposed pipes and conduit up to 249mm in diameter from pallet trucks and passing vehicles.
Galvanised beneath the finish
A hot-dip galvanised layer under the yellow powder coat keeps protecting against rust even if the surface gets scuffed.
Fixes at both ends
Bolts down at the base and fixes to a wall or upright at the top, so it does not rely on the wall alone.
High-visibility yellow and black
Powder-coated bands make the protector easy to spot in busy warehouse and yard traffic.
UK manufactured
Made in the UK from top-grade steel.
Overview
Vertical Pipe Protectors - Wall & Ground Mounted - Overview
A hot-dip galvanised and yellow powder-coated steel cage that protects exposed pipework or electrical conduit up to 249mm in diameter from vehicle impact. It fixes to a wall at the top and bolts down at the base, so it is supported at both ends.
249mm
Max pipe diameter
2mm
Tube wall thickness
8bolts
Fixing bolts required (not included)
| Dimensions | |
|---|---|
| Height | 1000mm / 1500mm |
| Width | 350mm |
| Depth | 300mm |
| Inside width | 250mm |
| Inside depth | 275mm |
| Tube diameter | 48mm |
| Wall thickness | 2mm |
| Weight | 15kg (1000mm) / 21kg (1500mm) |
| Details | |
|---|---|
| Material | Top-grade steel |
| Finish | Hot-dip galvanised, powder-coated |
| Colour | Yellow and black |
| Fixing | Bolt down, 8 bolts required (not included) |
| Use | Indoor and outdoor |
| Max pipe diameter | 249mm |
| Origin | Manufactured in the UK |
Frequently asked questions
Does it need fixing to a wall, or can it stand alone on the floor?
Does it need fixing to a wall, or can it stand alone on the floor?
Both - it bolts down at the base and fixes to a wall or upright at the top, so it is supported at both ends rather than relying on the wall alone.
How big a pipe can it protect?
How big a pipe can it protect?
Up to 249mm in diameter.
How many bolts do I need, and are they included?
How many bolts do I need, and are they included?
8 bolts in total, across the base and the top fixing plate - sold separately.
Will it hold up outdoors?
Will it hold up outdoors?
Yes - it is hot-dip galvanised beneath the yellow powder coat, so it is rated for indoor and outdoor use.
Which height should I pick?
Which height should I pick?
Two heights are available, 1000mm and 1500mm - measure the pipework you need to cover before ordering.
How much does each size weigh?
How much does each size weigh?
15kg for the 1000mm version, 21kg for the 1500mm version.
